TP-Link EAP115-Wall 300Mbps Wireless N Wall-Plate Access Point | T16

Description Model: EAP115-Wall TP-Link 300Mbps Wireless N Wall-Plate Access Point Overview Easy-mount construction allows installation into any standard EU-type data wall-box Compact, low-profile design fits discreetly with any existing interior style Free Auranet Controller Software enables administrators to easily manage hundreds of EAPs Support Power over Ethernet (802.3af) for convenient and affordable installation Enterprise class Wi-Fi security helps to decrease network security threats Captive portal provides one convenient method of authentication for Wi-Fi guests Supports management vlan for an enhanced network management Specifications HARDWARE FEATURES Interface 10/100Mbps Ethernet (RJ-45) Port *2 Physical Security Lock – Button LED/Wi-Fi Button、RESET Power Supply PoE(IEEE 802.3af) Power Consumption 2.8 W Dimensions ( W x D x H ) 3.4×3.4×1.2 in. (86.8*86.8*30.2 mm) Antenna Type Internal 2*1.8dBi Omni Mounting Wall Plate Mounting Hardware Watch Dog Yes WIRELESS FEATURES Wireless Client Capacity 100 * Wireless Standards IEEE 802.11n/g/b/a Frequency 2.4GHz Signal Rate 11n: Up to 300Mbps(dynamic) 11g: Up to 54Mbps(dynamic) 11b: Up to 11Mbps(dynamic) Transmit Power CE： <15dBm(2.4GHz) Wireless Functions Multiple SSIDs（Up to 8 SSIDs） Enable/Disable Wireless Radio Automatic Channel Assignment Transmit Power Control (Adjust Transmit Power on dBm) QoS(WMM) Load Balance Rate Limit Reboot Schedule Wireless Schedule Wireless Statistics based on SSID/AP/Client Wireless Security Captive Portal Authentication Access Control Wireless Mac Address Filtering Wireless Isolation Between Clients SSID to VLAN Mapping Local LAN port based VLAN Rogue AP Detection 802.1X Support 64/128/152-bit WEP / WPA / WPA2-Enterprise, WPA-PSK / WPA2-PSK MANAGEMENT Omada App Yes Centralized Management • Omada Hardware Controller (OC300) • Omada Hardware Controller (OC200) • Omada Software Controller Cloud Access Yes. Requiring the use of OC300, OC200, or Omada Software Controller. Email Alerts Yes LED ON/OFF Control Yes Management MAC Access Control Yes SNMP v1,v2c System Logging Local/Remote Syslog Local/Remote Syslog SSH Yes Web-based Management HTTP/HTTPS L3 Management Yes Multi-site Management Yes Management VLAN Yes OTHERS Certification CE, RoHS Package Contents 300Mbps Wireless N Wall-Plate Access Point EAP115-Wall Installation Guide Mounting Screw System Requirements Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10 Environment Operating Temperature: 0℃~40℃ (32℉~104℉) Storage Temperature: -40℃~70℃ (-40℉~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing Related
